Makita LS1019L 10-Inch Dual-Bevel Sliding Compound Miter Saw with Laser
Makita LS1019L 10-Inch Dual-Bevel Sliding Compound Miter Saw with Laser
Makita LS1019L 10-Inch Dual-Bevel Sliding Compound Miter Saw – jobsite-ready power and precision for contractors, workshops and serious DIYers.
Makita LS1019L 10-Inch Dual-Bevel Sliding Compound Miter Saw with Laser
Compact Rail-Forward Design with Professional Cutting Capacity and Precision Laser Guidance
The Makita LS1019L 10-Inch Dual-Bevel Sliding Compound Miter Saw with Laser combines impressive cutting capacity, precision, portability, and efficient dust extraction in a compact professional design. Its unique two-steel-rail sliding system creates a reduced footprint that allows the saw to operate flush against a wall, making it an excellent choice for jobsites where workspace is limited.
Powered by a 15-amp direct-drive motor, the LS1019L delivers consistent power without belts that can slip or require replacement. Soft start technology provides smoother start-ups, while electronic speed control maintains a consistent speed under load for smoother, higher-quality cuts.
The saw is engineered for substantial vertical cutting capacity, including 6-5/8-inch nested crown molding, 5-1/4-inch baseboard, and 12-inch crosscuts at 90°, providing the capacity associated with larger miter saws while maintaining a more compact form factor.
Key Features
Compact Two-Rail Sliding System
The unique two-steel-rail sliding system positions the rails to reduce the saw’s overall footprint. This allows the LS1019L to be positioned closer to a wall while maintaining sliding functionality.
Its compact design also contributes to easier jobsite transportation and storage.
High Vertical Cutting Capacity
The direct-drive gearbox and guard system are engineered to maximize vertical cutting capacity.
The LS1019L can accommodate:
- Up to 6-5/8 in. crown molding, vertically nested
- Up to 5-1/4 in. baseboard, vertically
- Up to 12 in. crosscuts at 90°
This provides the crown molding capacity associated with a 12-inch miter saw while using a 10-inch blade.
15-Amp Direct-Drive Motor
The powerful 15.0-amp direct-drive motor produces up to 3,200 RPM for efficient cutting performance.
Direct-drive technology eliminates the need for drive belts, helping provide:
- Smooth start-ups
- Consistent power delivery
- Reduced maintenance
- No belts to slip or replace
Soft Start
The soft-start function gradually brings the motor up to operating speed, helping suppress start-up reaction and contributing to smoother operation and longer gear life.
Electronic Speed Control
Electronic speed control helps maintain a consistent blade speed under load, supporting smoother and more controlled cuts when working through demanding materials.
Wide Miter Range
The LS1019L provides a 0° to 60° miter range to both the left and right, with positive stops at common angles for fast, repeatable positioning.
Positive stops include:
- 0°
- 15°
- 22.5°
- 31.6°
- 45°
- 60°
Dual-Bevel Capability
The front-mounted bevel lock provides convenient access for quick adjustments. The saw bevels from 0° to 48° left and right, allowing compound cuts without repeatedly repositioning the workpiece.
Integrated Laser Guide
The built-in laser indicates the line of cut whether the blade is running or stationary. Micro-adjustment capability allows the laser to be positioned for precise left-of-blade or right-of-blade cutting.
See-Through Blade Guard
The high-visibility blade guard provides an unobstructed view of the blade and cutting area, helping users align the workpiece with the intended line of cut.
Linear Ball Bearing System
The linear ball bearing sliding system is engineered to provide smooth movement and accurate positioning for consistent cuts.
Electric Brake
An integrated electric brake quickly stops the blade after the trigger is released, improving convenience and productivity between cuts.
Dust Collection
The LS1019L features an improved dust collection system designed for efficient debris management.
Key features include:
- Dual dust collection ports
- Included dust bag
- Vacuum compatibility
- Improved dust collection capability
A compatible vacuum is sold separately.
Stable Aluminum Base
The large aluminum base provides a stable platform for supporting cutting stock. Its substantial design helps improve workpiece stability and contributes to more efficient, controlled cutting.
Ergonomic Design
The LS1019L is designed with jobsite portability and user comfort in mind.
Features include:
- Ergonomic rubberized horizontal D-handle
- Oversized trigger switch
- Compact footprint
- 57.9 lb weight
- Easy one-touch slide lock
- Simple miter lock/unlock mechanism
- Large, easy-to-read miter scale
- Dual bevel scale
- Convenient front bevel lock
Precision Adjustment Features
Stainless Steel Miter Scale
The replaceable stainless steel miter scale features large, easy-to-read markings for quick and accurate angle selection.
Dual Bevel Scale
Easy-to-read bevel scales help users make more precise adjustments when setting compound cuts.
One-Touch Slide Lock
The convenient one-touch slide lock makes it easier to secure and release the sliding mechanism.
Miter Lock
A simple 90° turn-of-the-knob mechanism provides quick miter angle locking and unlocking.
Blade & Cutting Performance
The LS1019L includes a 60-tooth carbide-tipped blade designed for precision cutting.
The saw’s high-power motor is also capable of cutting wood and aluminum extrusion when equipped with the appropriate blade and cutting lubricant. An aluminum-cutting blade and cutting lubricant are sold separately.
Technical Specifications
| Specification | Details |
|---|---|
| Model | LS1019L |
| Product Type | Sliding Compound Miter Saw |
| Blade Diameter | 10 in. |
| Motor | Direct Drive |
| Motor Power | 15.0 Amp |
| No-Load Speed | 3,200 RPM |
| Bevel Type | Dual Bevel |
| Bevel Range | 0°–48° Left / Right |
| Miter Range | 0°–60° Left / Right |
| Weight | 57.9 lb |
| Sliding System | Two-Steel-Rail |
| Laser Guide | Built-In, Micro-Adjustable |
| Dust Collection | Dual Ports |
| Blade Included | 60T Carbide-Tipped |
| Electric Brake | Yes |
| Soft Start | Yes |
| Electronic Speed Control | Yes |
Cutting Capacity
| Application | Maximum Capacity |
|---|---|
| Crown Molding – Vertically Nested | 6-5/8 in. |
| Baseboard – Vertical | 5-1/4 in. |
| Crosscut at 90° | Up to 12 in. |
Miter Positions
| Angle | Positive Stop |
|---|---|
| 0° | Yes |
| 15° | Yes |
| 22.5° | Yes |
| 31.6° | Yes |
| 45° | Yes |
| 60° | Yes |
Included Accessories
The LS1019L includes:
- 60T carbide-tipped blade
- Dust bag
- Built-in laser guide
- Integrated upper and lower fence system
Ideal Applications
The Makita LS1019L is well suited for:
- Finish carpentry
- Crown molding
- Baseboard installation
- Trim work
- Framing
- Remodeling
- General construction
- Professional woodworking
- Compound miter cuts
- Bevel cuts
- Crosscutting
- Cutting wood and compatible aluminum extrusion with appropriate accessories
Safety & Operating Guidance
For safe and effective operation:
- Follow all Makita operating and safety instructions.
- Wear appropriate eye and hearing protection.
- Keep hands away from the blade and cutting path.
- Secure the workpiece firmly before cutting.
- Allow the blade to reach a complete stop before making adjustments or removing material.
- Disconnect the saw from its power source before blade changes or maintenance.
- Use the appropriate blade for the material being cut.
- Use appropriate dust extraction when required.
- Inspect the blade, guards, fences, and power cord before operation.
- Ensure the saw is securely positioned on a stable work surface.
Why Choose the Makita LS1019L?
The Makita LS1019L 10-Inch Dual-Bevel Sliding Compound Miter Saw delivers the cutting capacity of a larger saw in a more compact and portable package. Its 6-5/8-inch crown molding capacity, 5-1/4-inch baseboard capacity, and 12-inch 90° crosscut capacity make it well suited for demanding trim and construction applications.
With a 15-amp direct-drive motor, 3,200 RPM output, dual-steel-rail sliding system, dual bevel capability, micro-adjustable laser, electronic speed control, soft start, electric brake, and dual dust ports, the LS1019L is designed to provide accurate, efficient, and convenient cutting performance on professional jobsites.
