SHOP FOX W1715 3/4 HP Metal Cutting Bandsaw – jobsite-ready power and precision for contractors, workshops and serious DIYers.
The Shop Fox W1715 Metal-Cutting Bandsaw is designed for dependable metal-cutting performance in a compact and portable package. Powered by a 3/4 HP, 110V single-phase motor, this bandsaw offers three blade-speed settings to accommodate different cutting requirements.
Built with portability in mind, the W1715 features handles and wheels for easy movement, along with an automatic shutoff and integrated brake for added convenience during operation. A metal-cutting blade and stand are included, making it a practical addition to fabrication, maintenance, and general metalworking applications.
Key Features
3/4 HP Motor
- 3/4 HP motor
- 110V, single-phase electrical system
- Motor speed: 1,725 RPM
- Designed for metal-cutting applications
Three Blade Speeds
The W1715 provides three blade-speed settings to accommodate different metal-cutting requirements:
- 78 FPM @ 40 RPM
- 108 FPM @ 60 RPM
- 180 FPM @ 80 RPM
The multiple speed options allow the operator to select an appropriate cutting speed for the material and application.
Portable Design
- Equipped with handles and wheels
- Designed for convenient movement around the workshop
- Compact overall dimensions help minimize workspace requirements
- Stand included
Automatic Shutoff
- Automatic shutoff feature helps stop the machine after a cutting operation
- Supports convenient unattended completion of a cut when properly set up
Brake
- Integrated brake provides an additional stopping feature
- Designed for controlled machine operation
Included Blade
- Metal-cutting blade included
- Blade dimensions: 64-1/2 × 1/2 × 0.025 in.
- Rectangular blade profile
- 24 teeth
Specifications
Machine Specifications
| Specification | Details |
|---|---|
| Brand | Shop Fox |
| Model | W1715 |
| Part Number | W1715 |
| Machine Type | Metal-Cutting Bandsaw |
| Color | Black & White |
| Motor | 3/4 HP |
| Motor Speed | 1,725 RPM |
| Voltage | 110V |
| Phase | Single-Phase |
| Power Source | Corded Electric |
| Recommended Material | Metal |
| Blade Speed | 78 / 108 / 180 FPM |
| Blade Length | 64.5 in. |
| Blade Size | 64-1/2 × 1/2 × 0.025 in. |
| Blade Material | Metal |
| Number of Teeth | 24 |
| Cutting Angle | 90° |
| Blade Shape | Rectangular |
| Product Dimensions | 41 in. L × 18 in. W × 14 in. H |
| Special Features | Brake, Automatic Shutoff, Portability |
| Stand | Included |
Blade Speed
| Setting | Blade Speed | Motor Speed |
|---|---|---|
| Low | 78 FPM | 40 RPM |
| Medium | 108 FPM | 60 RPM |
| High | 180 FPM | 80 RPM |
Included Components
The Shop Fox W1715 includes:
- Metal-cutting bandsaw
- Stand
- Metal-cutting blade
- Handles and wheels for portability
Applications
The Shop Fox W1715 is suited for a variety of metalworking tasks, including:
- Metal fabrication
- Workshop maintenance
- Cutting metal stock
- General fabrication work
- Repair applications
- Small-shop metalworking
- Portable cutting operations
Safety & Convenience
The W1715 incorporates several features designed to make operation more convenient, including an automatic shutoff, brake, handles, and wheels. The automatic shutoff is designed to stop the machine at the appropriate point in the cutting cycle.
Always secure the workpiece properly, select the appropriate blade speed and blade for the material, and follow the manufacturer’s operating and safety instructions.
Warranty
The Shop Fox W1715 is backed by a 2-year manufacturer’s warranty.
Why Choose the Shop Fox W1715?
The Shop Fox W1715 combines a compact design with a 3/4 HP motor, three blade-speed settings, portability features, automatic shutoff, and an integrated brake. Its 110V electrical system makes it suitable for workshops requiring a dedicated metal-cutting bandsaw with convenient mobility and straightforward operation.
